ASTM B265 titanium sheet supplier for chemical equipment

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

ASTM B265 Titanium Sheet Supplier for Chemical Equipment | Gr2 Cut-to-Size Stock

Meta Description: ASTM B265 Gr2 titanium sheet supplier for chemical equipment. Ready stock 400 tons, cut-to-size zero cutting, MTC EN 10204 3.1, export packing, same-day dispatch. Baoji stockist, quote within 24h.

Overview

We are a Baoji-based titanium inventory holder and supplier with 800 tons total titanium stock, including 400 tons of Titanium Plate and sheet in various grades, thicknesses, and dimensions. As a stockist, we provide zero-cutting (cut-to-size) service, accept small MOQ orders, read fabrication drawings, understand ASTM/EN/GB standards, handle export packaging, and arrange same-day dispatch for in-stock items confirmed before cut-off time.

This page focuses on ASTM B265 titanium sheet for chemical equipment: the grades, dimensions, and documentation we supply to equipment fabricators building heat exchangers, reactors, tanks, desalination evaporators, and corrosion-resistant process lines. All information is verified by our technical team. For pricing, send your drawing or specification (grade, size, quantity) to our sales team.

Product Range & Available Grades

Grade	Standard	Typical Form	Stock Status
Gr1 (TA1)	ASTM B265	Sheet/Plate	In stock
Gr2 (TA2)	ASTM B265	Sheet/Plate, 0.5–50mm	400 tons ready
Gr4 (TA4)	ASTM B265	Plate, thick section	On request
Gr5 (TC4)	ASTM B265 / AMS 4911	Plate, aerospace grade	Selected sizes
Gr7	ASTM B265	Corrosion-resistant plate	On request
Gr12	ASTM B265	Low-cost alloy plate	On request
TA10	GB/T 3621	Domestic standard plate	In stock

Note: All plates supplied with Mill Test Certificate (MTC) per EN 10204 3.1 as default. Third-party inspection (SGS/BV/TUV) available on request.

Why Gr2 for Chemical Equipment

Gr2 (TA2) is the grade most often specified for chemical process equipment among the commercially pure titanium sheets we stock. It is the practical balance of corrosion resistance, formability, and cost for chloride-containing and oxidizing media.

Property	Relevance to chemical equipment
Corrosion resistance	Resists seawater, wet chlorine, nitrates, and most organic acids; forms a stable passive oxide film
Formability	Readily rolled, formed, and welded for vessel shells, liners, and dished heads
Density 4.51 g/cm³	Lighter than stainless steel, reducing support and skid weight
Annealed strength	Tensile ≥345 MPa, yield ≥275 MPa, elongation ≥20% per ASTM B265
Weldability	Argon-shielded TIG/MIG welds well; suitable for vessel and lining work

Selection note: For strong reducing acids or high-temperature brine with crevice-corrosion risk, Gr7 (Pd-added) or Gr12 (Mo-Ni alloy) may be the better choice. Send us the medium, temperature, and concentration — we review before quoting and do not substitute grade without written confirmation.

Technical Parameters

Parameter	Specification
Thickness range	0.5mm – 50mm (sheet: 0.5–4mm; plate: 5–50mm)
Width	1000mm / 1219mm / 1500mm / cut to spec
Length	2000mm / 3000mm / 6000mm / cut to spec
Surface finish	Pickled, sandblasted, polished (per request)
Edge	Mill edge / slit edge / trimmed
Tolerance	Per ASTM B265 or customer drawing
Flatness	≤ 3mm/m (typical, verified before dispatch)

Inventory Snapshot (Real-Time Estimate)

Our current Titanium Plate and sheet inventory is approximately 400 tons, distributed as follows:

• Gr2 plate 3–12mm thickness: ~180 tons (most active stock, multiple widths)
• Gr2 plate 0.5–2mm thin sheet: ~45 tons
• Gr2 plate 15–50mm thick plate: ~120 tons
• Gr5 / TC4 alloy plate: ~25 tons
• Gr1 / Gr4 / Gr7 specialty grades: ~30 tons

Important: Stock rotates daily. Contact us for live availability before placing order. We update inventory weekly.

Zero-Cutting Service (Cut-to-Size)

As an inventory holder, we do not only sell full plates. Our workshop provides:

• Shearing for plates ≤ 12mm thickness
• Plasma cutting for plates 12–50mm
• Waterjet cutting for precision profiles (tolerances ±0.5mm)
• Band saw cutting for block/blank preparation

Cutting is performed after order confirmation, based on customer drawings or dimension specifications. Small offcuts from zero-cutting are available at reduced rates upon request.

Applications by Industry

Industry	Application	Recommended Grade
Chemical processing	Heat exchanger plates, reactor lining, tank walls	Gr2, Gr7
Seawater desalination	Evaporator plates, piping shields	Gr2, Gr12
Power generation	Condenser plates, flue gas scrubbers	Gr2, Gr7
Medical	Implant substrate, surgical instrument blanks	Gr1, Gr23 (on request)
Aerospace	Structural plates, firewall components	Gr5 (TC4)
Architecture	Cladding, façade panels	Gr1, Gr2
Electrolysis	Anode substrates, plating tanks	Gr2, Gr5

Export & Packaging

• Export packaging: Wooden crate with moisture barrier, foam protection on edges, steel banding
• Marking: Grade, heat number, dimensions, standard etched or tagged
• Documents provided: Commercial invoice, packing list, MTC (EN 10204 3.1), certificate of origin, material safety data sheet (MSDS)
• Shipping terms: EXW, FOB Shanghai/Tianjin, CIF, DAP available
• Dispatch time: Same day for stock items cut before 3 PM (China time), subject to cutting queue and order volume

Quality Assurance

• All plates sourced from certified mills (BAOTI, Western Titanium, or equivalent)
• Incoming inspection: thickness gauge, ultrasonic testing (UT) for plates ≥ 20mm
• Dimensional check before dispatch
• MTC cross-verified against mill heat number
• No substitution without customer written confirmation

Customization & Non-Standard Requests

We accept:

• Non-standard thickness rolling (lead time 4–8 weeks)
• Special surface treatment (mirror polish, anodizing, coating)
• Drilling, countersinking, bending (per drawing)
• Welding preparation (beveling, edge chamfering)

For non-standard items, send drawing in PDF/DWG/STEP format. Our engineering team reviews feasibility and responds within 24 hours.

FAQ — Frequently Asked Questions

Q1: Do you sell full plates or only cut pieces?
A: We supply both. Full plates from stock or cut-to-size pieces starting from small offcuts. MOQ is flexible — we accept single-piece orders for standard sizes.

Q2: What is your typical lead time for cut plates?
A: For in-stock Gr2 plates, cutting and dispatch within 24 hours if order confirmed before 3 PM China time. Thick plates (>20mm) or precision cutting (waterjet) may require 2–3 working days.

Q3: Can you provide third-party inspection?
A: Yes. SGS, BV, TUV inspection can be arranged at buyer's cost. We coordinate mill visit and material sampling.

Q4: What standards do your plates comply with?
A: Primary standard is ASTM B265. We also supply plates meeting AMS 4911 (aerospace), GB/T 3621 (Chinese domestic), and EN 485 (European) upon request.

Q5: How do you handle export customs and documentation?
A: We prepare full export documentation including commercial invoice, packing list, MTC, COO, and MSDS. For restricted destinations, additional certificates (e.g., dual-use declaration) may be required — please confirm with your local import regulations.

Q6: Can I get a small sample piece before bulk order?
A: Yes. Sample pieces (100×100mm or similar) can be cut from stock and shipped via courier (DHL/FedEx) at cost. Sample fee is deductible from subsequent bulk orders.

Q7: What payment terms do you accept?
A: T/T (30% advance, 70% before dispatch) is standard. L/C at sight accepted for orders above USD 10,000. Other terms negotiable for established customers.

Q8: How do you prevent plate surface damage during cutting and packing?
A: Each cut piece is interleaved with protective film or paper, edges padded with foam, and packed in wooden crate with moisture-proof lining. For thin sheets, we use flat steel frames to prevent bending.

Q9: Do you stock titanium clad plates?
A: We do not manufacture clad plates in-house, but we source from partner mills and supply as distributor. Lead time 2–4 weeks. Send your cladding ratio and base metal spec for quotation.

Q10: Can you match my drawing tolerances?
A: Yes. We cut to drawing dimensions with standard tolerance ±0.5mm for shearing, ±0.2mm for waterjet. Tighter tolerances available — specify on drawing. Our team reads both metric and imperial drawings.

Request a Quote

To receive a quotation, please provide:

1. Grade (e.g., Gr2, TA2, TC4)
2. Dimensions (thickness × width × length, or drawing)
3. Quantity (pieces or total kg)
4. Standard requirement (ASTM B265 / GB / EN / AMS)
5. Surface finish (pickled / polished / as-rolled)
6. Delivery destination (for freight estimation)
7. Required documents (MTC only / third-party inspection / COO)

Send to: sales@[yourdomain].com or via the contact form on this website. We respond within 24 hours with stock confirmation and pricing.

---

About Us: We are a titanium inventory holder and supplier based in Baoji, China — the "Titanium Valley." With 800 tons total stock across plate, tube, bar, wire, fittings, flange, fasteners, nickel products, and non-standard equipment, we serve overseas procurement clients with cut-to-size service, drawing review, standard compliance, and export-ready delivery. Same-day dispatch available for confirmed in-stock orders.
