Gr12 Titanium Plate ASTM B265 for Reducing Acid Chemical Equipment

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Overview

We supply Gr12 Ti-Mo-Ni Titanium Alloy Plate complying with ASTM B265 located in Baoji, China Titanium Valley. As a professional titanium inventory supplier, we keep stock of Gr12 Titanium Plate as economical alternative to Gr7 titanium palladium alloy. We can interpret chemical equipment engineering drawings, provide custom cutting service, fully comply with ASTM B265 standards. Full-set export documents and EN10204 3.1 MTC material test certificates are available for each batch, qualified in-stock items support same-day shipment.

Core Specifications

Available Grade	Gr12 Titanium Alloy (Ti-0.3Mo-0.8Ni)
Product Type	Titanium Plate / Titanium Sheet
Thickness	1mm‑40mm
Size	Standard plate or cut-to-size per chemical vessel fabrication drawings
Surface Condition	Hot rolled, pickled surface; sandblasted surface optional
Applicable Standards	ASTM B265 / ASME SB265
Certificates	ISO9001, EN10204 3.1 MTC, ultrasonic inspection report available

Key Benefits

• Good resistance to reducing acid and chloride mixed solution, economical replacement of expensive Gr7 alloy
• Stable passive film in hot dilute reducing acid media where Gr2 pure titanium cannot work
• Excellent ductility and weldability for reactor shell, tank lining and heat exchanger fabrication
• Strong resistance to crevice corrosion under halogen ion containing corrosive environment
• Lower material cost without sacrificing core corrosion performance, reduce total project budget

Grade Description

Gr12 (Ti-0.3Mo-0.8Ni) is titanium molybdenum nickel alloy specified under ASTM B265. Without expensive palladium addition, it delivers good anti-corrosion performance in reducing acid, serving as a popular cost-saving alternative to Gr7. Our Gr12 plate is widely supplied for chemical EPC projects in South Korea, Poland and Vietnam.

Product Features

Our hot rolled Gr12 Ti-Mo-Ni plate is pickled to remove oxide scale. Every plate passes ultrasonic inspection to detect internal lamination defects. Gr12 Titanium Plate is widely applied for chemical reactors, storage tanks and heat exchangers handling dilute reducing acid mixed with chloride ions.

Industry Applications

• Chemical industry: reducing acid reactor, corrosive liquid storage tank, heat exchanger lining
• Wet metallurgy projects with mixed chloride and weak reducing acid media
• Chemical equipment EPC and fabrication projects in South Korea, Poland and Vietnam

Quality Assurance

Every batch undergoes strict inspection before shipment:

• Full dimension tolerance inspection
• Ultrasonic testing (UT)
• Tensile & hardness mechanical property testing
• Chemical composition testing for Mo and Ni content
• Material Test Certificate (MTC) supplied for traceability

Our Service Advantages

• ✅ Spot stock available for fast delivery
• ✅ Custom cutting service, cut‑to‑size according to chemical equipment drawings
• ✅ Professional drawing interpretation, support non‑standard dimension processing
• ✅ ISO9001 certified, MTC certificates provided for each shipment
• ✅ Meet ASTM, ASME and GB international standards
• ✅ Global export service, same‑day shipment for in‑stock goods

Packaging & Shipment

Protective film + foam cushion + heavy-duty seaworthy plywood case. Support small trial order and bulk container shipment for chemical manufacturers. UT and chemical composition reports available for client material audit.

FAQ

Q: What is the difference between Gr12 and Gr7 Titanium Plate?
A: Gr12 is Ti-Mo-Ni alloy, no palladium. It provides similar anti-corrosion performance in many reducing acid scenarios at lower cost, as a cost-effective substitute of Gr7 Ti-Pd alloy.

Q: When should we choose Gr12 instead of Gr7?
A: Gr12 is preferred for projects with budget constraints, working under moderate reducing acid and chloride conditions, while Gr7 is selected for harsher and more demanding corrosive environments.

Q: Can you cut Gr12 Titanium Plate to custom sizes for tank fabrication?
A: Yes. Our engineering team can read chemical vessel drawings and cut Gr12 plate into required blank sizes.

If you have technical specifications or project requirements, feel free to send us your inquiry for quotation.
