Gr7 Titanium Plate ASTM B265 for Strong Corrosive Reducing Acid Environment

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Overview

We supply Gr7 Titanium Palladium Alloy Plate complying with ASTM B265 located in Baoji, China Titanium Valley. As a professional titanium inventory supplier, we stock premium Gr7 titanium palladium plate. We can interpret chemical reactor engineering drawings, provide custom cutting service, fully comply with ASTM B265 standards. Full-set export documents and EN10204 3.1 MTC material test certificates are available for each batch, qualified in-stock items support same-day shipment.

Core Specifications

Available Grade	Gr7 Titanium Palladium Alloy (Ti-0.15Pd)
Product Type	Titanium Plate / Titanium Sheet
Thickness	1mm‑40mm
Size	Standard plate or cut-to-size per chemical equipment fabrication drawings
Surface Condition	Hot rolled, pickled surface; sandblasted surface optional
Applicable Standards	ASTM B265 / ASME SB265
Certificates	ISO9001, EN10204 3.1 MTC, ultrasonic inspection report available

Key Benefits

• Outstanding resistance to reducing acid corrosion, where Gr2 pure titanium fails easily
• Palladium addition stabilizes passive film under low pH, chloride-containing reducing media
• Excellent ductility and weldability for manufacturing chemical reactors and storage vessels
• High resistance to crevice corrosion in mixed acid and halogen ion service conditions
• Long service life, lower downtime and maintenance cost for continuous chemical production

Grade Description

Gr7 (Ti-0.15Pd) is titanium palladium alloy defined by ASTM B265. Small palladium content greatly improves corrosion resistance in reducing acid environments, which distinguishes it from Gr2 pure titanium. Our Gr7 plate is widely used for fine chemical and metallurgy EPC projects in Mexico, Spain and Malaysia.

Product Features

Our hot rolled Gr7 titanium palladium plate is pickled to remove oxide scale. Every plate is inspected by ultrasonic testing to detect internal defects. Gr7 Titanium Plate is commonly used for reactor shells, heat exchanger liners and storage tanks handling reducing acid mixed with chloride ions.

Industry Applications

• Fine chemical & pharmaceutical: reducing acid reactor, corrosive medium storage tank, heat exchanger lining
• Wet metallurgy with mixed chloride and reducing acid media
• Chemical equipment EPC projects in Mexico, Spain and Malaysia

Quality Assurance

Every batch undergoes strict inspection before shipment:

• Full dimension tolerance inspection
• Ultrasonic testing (UT)
• Tensile & hardness mechanical property testing
• Precise chemical composition testing for palladium content
• Material Test Certificate (MTC) supplied for traceability

Our Service Advantages

• ✅ Spot stock available for fast delivery
• ✅ Custom cutting service, cut‑to‑size according to chemical equipment drawings
• ✅ Professional drawing interpretation, support non‑standard dimension processing
• ✅ ISO9001 certified, MTC certificates provided for each shipment
• ✅ Meet ASTM, ASME and GB international standards
• ✅ Global export service, same‑day shipment for in‑stock goods

Packaging & Shipment

Protective film + foam cushion + heavy-duty seaworthy plywood case. Bulk and small batch shipment both supported for chemical equipment manufacturers. UT and chemical test reports can be attached for client material audit.

FAQ

Q: What is the difference between Gr7 and Gr2 Titanium Plate?
A: Gr7 is Ti-0.15Pd titanium palladium alloy. It maintains good corrosion resistance in reducing acid environments, while Gr2 pure titanium will suffer corrosion under such conditions.

Q: Can you cut Gr7 titanium palladium plate for reactor fabrication?
A: Yes. Our engineering team can read chemical equipment drawings and cut Gr7 plate to required blank sizes.

Q: Can you provide full MTC including palladium composition test report?
A: Yes, EN10204 3.1 MTC with full chemical composition report and UT inspection documents can be supplied for tender and material qualification.

If you have technical specifications or project requirements, feel free to send us your inquiry for quotation.
