GB/T 3621 vs ASTM B265: Titanium Plate
| Reference Price | $10.00 – $12.00 |
|---|
Product Description: GB/T 3621 vs ASTM B265 comparison: chemical composition, mechanical properties, dimensional tolerances, certification equivalence, and procurement cross-reference for titanium plate buyers.
Product Overview
Titanium Plate Supplier – Grade 2, 5, 7, 12 | ASTM B265 & GB/T 3621Titanium Plate Supplier – Grade 2, 5, 7, 12 | ASTM B265 & GB/T 3621
Direct from mill in Baoji, China. Reviewed by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.
Need a Quote for Titanium Plate?
Tell us your grade, thickness, dimensions, and quantity. We reply within 24 hours with pricing and lead time.
Get a Free Quote →Or WhatsApp: +86 188 2967 9311 | Email: sales@sxqytd.com
1. Available Grades at a Glance
Grade 2 (UNS R50400) — The Universal Default
Best for: Chemical processing, heat exchangers, marine, desalination, general corrosion service.
Why choose it: Best balance of corrosion resistance, formability, and weldability. The workhorse of Titanium Plate — 70% of all Titanium Plate orders are Gr2. Read our ASTM B265 specification guide for full technical details.
Stock status: [FILL: e.g. "Thickness 1-20mm in stock, widths 1000/1219/1500mm, lengths 2000/3000/6000mm"]
Grade 5 / Ti-6Al-4V (UNS R56400) — High Strength
Best for: Aerospace components, pressure vessels, high-strength structural parts, offshore, medical implants (ELI variant).
Why choose it: Tensile strength 895 MPa minimum (vs 345 MPa for Gr2). Same corrosion resistance as Gr2 with 2.5× the strength. Heavier and more expensive, but essential where weight savings and strength both matter.
Stock status: [FILL: e.g. "Thickness 3-50mm in stock, annealed condition, AMS 4911 available"]
Grade 7 (UNS R52400) — Pd-Enhanced Corrosion Resistance
Best for: Aggressive chemical environments, reducing acids, chloride-bearing services where Gr2 may be marginal.
Why choose it: Gr2 + 0.12–0.25% palladium. The Pd addition provides enhanced crevice and pitting corrosion resistance in hot brine, wet chlorine, and hypochlorite solutions. See our Grade 7 material guide for composition details.
Stock status: [FILL: e.g. "Thickness 2-12mm available, made-to-order for thicker"]
Grade 12 (UNS R53400) — Ti-0.3Mo-0.8Ni
Best for: High-temperature chemical service, sour gas (H₂S), reducing acid environments.
Why choose it: Intermediate strength between Gr2 and Gr5, with superior creep resistance and corrosion resistance in reducing acids. More cost-effective than Gr7 for many chemical applications.
Stock status: [FILL: e.g. "Thickness 3-20mm, made-to-order, 3-4 week lead time"]
2. Technical Specifications by Grade
| Property | Grade 2 (R50400) | Grade 5 (R56400) | Grade 7 (R52400) | Grade 12 (R53400) |
|---|---|---|---|---|
| Standard | B265 / GB/T 3621 | B265 / GB/T 3621 | B265 / GB/T 3621 | B265 / GB/T 3621 |
| Tensile strength (min) | 345 MPa | 895 MPa | 345 MPa | 483 MPa |
| Yield strength (min) | 275 MPa | 828 MPa | 275 MPa | 345 MPa |
| Elongation (min) | 20% | 10% | 20% | 18% |
| Density | 4.51 g/cm³ | 4.43 g/cm³ | 4.51 g/cm³ | 4.52 g/cm³ |
| Key alloying | CP Ti | 6% Al, 4% V | CP Ti + 0.15% Pd | 0.3% Mo, 0.8% Ni |
| Relative cost index | 1.0 (baseline) | 1.8–2.2 | 1.5–1.8 | 1.4–1.6 |
Need help choosing? Read our GB/T 3621 vs ASTM B265 comparison guide to understand standard equivalence and dual certification options.
3. Thickness, Width & Length Capabilities
| Parameter | Range | Tolerance | Note |
|---|---|---|---|
| Thickness (plate) | [FILL: e.g. "3.0–100mm"] | [FILL: e.g. "±0.15mm for 3-5mm, ±0.25mm for 5-10mm"] | Hot-rolled |
| Thickness (sheet) | [FILL: e.g. "0.5–3.0mm"] | [FILL: e.g. "±0.05mm for cold-rolled"] | Cold-rolled, pickled |
| Width | [FILL: e.g. "500–2000mm"] | [FILL: e.g. "+10/0mm"] | Sheared or plasma-cut |
| Length | [FILL: e.g. "1000–6000mm standard, up to 12000mm"] | [FILL: e.g. "+15/0mm"] | Custom lengths available |
Typical stock sizes (Gr2): [FILL: list 5-8 common stock sizes, e.g. "3×1219×2438mm, 5×1500×3000mm, 6×1500×6000mm, 10×2000×6000mm"]
Typical stock sizes (Gr5): [FILL: list common stock sizes]
4. Surface Conditions & Processing
| Surface | Process | Typical use |
|---|---|---|
| Hot-rolled (black) | As-rolled, oxide scale present | Rough machining blanks, non-visible applications |
| Pickled | HF+HNO₃ acid cleaning removes oxide | General-purpose, most common |
| Sandblasted | Grit blasting for uniform matte finish | Architectural, visible surfaces |
| Polished | Abrasive polishing to specified Ra | Medical, food, high-purity chemical |
Surface roughness (polished): [FILL: e.g. "Ra 0.8–3.2μm available on request"]
5. Certification & Quality Documentation
Every order includes:
- EN 10204 3.1 MTR — heat chemistry, mechanical properties, UNS designation
- Dual certification — ASTM B265-20 and GB/T 3621-2022 on single certificate
- Heat traceability — from ingot to finished plate
- PMI verification — XRF on every heat for Gr7 (Pd) and Gr12 (Mo/Ni)
Optional documentation:
- Third-party inspection (SGS, BV, TUV) at mill before shipment
- Ultrasonic testing per ASTM A578 / EN 10160
- Free-iron test per ASTM A380
- ASME material certification [FILL: if your mill holds ASME approval, state it here; otherwise remove this line]
6. Cut-to-Length & Value-Added Services
| Service | Capability | Tolerance |
|---|---|---|
| Shearing | Up to [FILL: e.g. "12mm thickness"] | ±1.5mm |
| Plasma cutting | Up to [FILL: e.g. "50mm thickness"] | ±2mm |
| Waterjet cutting | Up to [FILL: e.g. "100mm thickness"] | ±0.2mm |
| Laser cutting | Up to [FILL: e.g. "6mm thickness"] | ±0.1mm |
Additional services: Edge deburring, surface grinding, hole drilling, bending (for thickness ≤6mm), welding preparation (beveling). All cut pieces tagged with heat number for full traceability.
Lead time: Stock sizes ship within [FILL: e.g. "3-5 working days"]. Custom-cut plates: [FILL: e.g. "5-10 working days"]. Made-to-order from ingot: [FILL: e.g. "3-5 weeks"].
7. Packaging & Global Shipping
Export packaging:
- Each plate separated by polyethylene film or interleaving paper
- Bundles strapped with steel bands, wrapped in waterproof plastic
- Packed in plywood crates or steel-framed wooden boxes
- Moisture absorbers included for long-sea shipments
- Crate labeled with heat number, grade, dimensions, quantity, GW/NW
Shipping terms: FOB Shanghai / Tianjin / Qingdao; CIF / CFR to destination port; DDP available for select countries. [FILL: your preferred incoterms and typical shipping lines used]
Container loading: 20ft container holds approximately [FILL: e.g. "20-22 tons"] of plate depending on dimensions. 40ft high-cube available for lightweight large-format plates.
8. Frequently Asked Questions
Ready to Order? Get Your Quote Today.
Email us at sales@sxqytd.com or WhatsApp +86 188 2967 9311
Include: grade, thickness × width × length, quantity, destination port, required certifications.
Send Inquiry →Shaanxi Qianyi Tuoda Technology Co., Ltd — Baoji, China. Mill-direct titanium plate, ASTM B265 & GB/T 3621. Read our B265 standard guide | Compare GB/T 3621 vs B265.
