Titanium Condenser Tube Supplier with Fast Dispatch \| ASTM B338 Gr2 Seamless, MTC 3.1

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Titanium Condenser Tube Supplier with Fast Dispatch | ASTM B338 Gr2 Seamless

Meta Description: Titanium condenser tube supplier with fast dispatch from Baoji. ASTM B338 Gr2/TA2 seamless, annealed, 100% eddy current tested, EN 10204 3.1 MTC, cut-to-length, same-day dispatch on confirmed in-stock orders. Quote within 24h.

Overview

A condenser does not wait for a 6-week mill queue. When a power-plant surface condenser or desalination brine heater goes offline, the tube bundle is the bottleneck — and the fastest fix is a stock-grade Gr2 titanium tube, cut to the right length, with a certificate you can hand to QA without explaining.

We are a Baoji Titanium Valley inventory holder. Condenser tube in common ODs (19.05mm / 25.4mm and mid-range) sits on the shelf; we cut, cap, NDT-verify, certify, and dispatch. Confirmed in-stock orders placed before 3 PM China time → same-day dispatch. No "we'll produce after deposit" theatre.

Why Titanium for Condensers (Engineering, Not Hype)

• Seawater, brackish water, high-chloride cooling water: no pitting, no crevice loss in normal service
• High flow velocity tolerated — thinner wall (0.5–1.2mm common) = more tubes per shell = better heat transfer
• Tube-to-tubesheet weld or roller expansion both work with clean argon practice
• Service life in desalination/MSF-MED commonly 20+ years; many plants report 25–30 years on original bundles
• Gr2 covers most seawater/brine duty; Gr7/Gr12 for hot reducing-acid or high-crevice-temperature service

We don't sell "immortal metal" — we sell a material whose life-cycle cost beats CuNi/316L when downtime is expensive.

ASTM B338 — What the Standard Actually Requires

ASTM B338 = seamless & welded titanium tubes for condensers and heat exchangers (ASME SB-338 equivalent context).

• Type S = seamless; Type W/WD = welded-and-drawn
• NDT: eddy current (ET) or ultrasonic (UT); hydrostatic/pneumatic per PO matrix
• Sample lot tests: flattening, flaring, tensile, chemistry
• Hydrostatic per B338: ~50% of min yield stress, held ≥5s (when specified)
• Straightness: ≤2.1mm/m for tubes over 10ft (B338 reference practice)

Stock Scope We Dispatch From

Live heat number confirmed before PI — no "yes everything in stock" bluff.

Technical Baseline (Gr2 / TA2, Annealed)

Fast Dispatch — What It Really Means

1. Enquiry with OD×wall×length×qty → stock check within 4 working hours
2. Quote: EXW/FOB, cutting method, ECT scope, MTC type, dispatch date
3. PO + payment confirmed → pull tagged stock (heat logged)
4. Cut to length → square end → inside/outside deburr → cap both ends
5. ECT per PO (100% on welded; seamless per NDT matrix)
6. MTC 3.1 drafted against mother-heat; QA cross-check tag=cert=crate
7. Dispatch same day if PO confirmed before 3 PM China time (in-stock gauge)

Air freight option available for shutdown emergencies (buyer cost, real-time quote). Sea freight FOB Shanghai default.

End Condition & Retubing Prep

• Plain end (square cut) — default
• Chamfered — for roller expansion
• Flare-ready — light deburr, clean oxide, argon-weld ready
• U-bend — mandrel bent, wall-thinning controlled, radius per drawing (project lead time)
• Tube-end sample for WPS qualification supplied on request

Rolling or welding? Tell us — we prep the end accordingly (lubricated for roll, clean for weld).

Testing & Certification

• 100% Eddy Current Test on welded tube; seamless per PO NDT matrix
• Hydrostatic / pneumatic on request (B338 stress basis)
• Flattening + flaring sample reports available
• EN 10204 Type 3.1 MTC — issued by the original tube mill's independent inspection function, heat-matched
• Chemistry + mechanicals for actual heat; ECT report referenced
• 3.2 (SGS/BV/TÜV) arranged at buyer cost
• Heat number on tag = MTC = bundle label. No mixed heat in one cert line.

Typical Condenser Applications

• Power-plant surface condensers (seawater/cooling-water cooled)
• MSF/MED desalination brine heaters & heat-recovery sections
• Refinery / petrochemical overhead condensers
• Chlor-alkali cooling coils, wet-Cl₂ gas lines
• Offshore topside exchangers, shipboard condensers
• Retubing old CuNi/316L bundles → titanium upgrade

Retubing Spare / Emergency Cuts

• Short lengths (150mm–2m) accepted, no forced full-stick buy
• Send old heat number → we match from shelf if live
• Mixed OD/wall in one crate OK
• Prototype / shutdown patch: 10–50 tubes cut same day (in-stock gauge)
• Expansion torque guidance shared; WPS qualified by your ASME shop

Export Packaging for Cut Tubes

• Plastic caps both ends (standard)
• PE sleeve per tube / per bundle
• Plywood divider crate (ISPM-15 fumigated)
• Steel strap + edge guard for long bundles
• Moisture barrier + desiccant for GCC/Africa long-sea
• Label: grade, OD×WT, length, heat No., PO ref

Enquiry Template (Copy-Paste)

Standard: ASTM B338
Grade: Gr2 / Gr9 / Gr7 / Gr12 ___
Type: Seamless (S) / Welded (WD)
OD × Wall: ___ mm × ___ mm
Cut length: ___ mm × ___ pcs
End: plain / chamfer / flare-ready / U-bend (R=___)
NDT: ECT standard / hydro yes-no / 3.1 or 3.2
Retubing: roll / weld / unknown (we advise)
Heat: any in-stock / match previous ___
Port: ___ (FOB Shanghai default)
Shutdown date: ___ (for dispatch priority)

FAQ — Titanium Condenser Tube, Fast Dispatch

Q1: How fast can you really ship?
A: In-stock gauge + PO confirmed before 3 PM China time → same-day dispatch. Air option for emergencies; sea FOB Shanghai standard. We quote the dispatch date in the PI, not "soon".

Q2: Gr2 or Gr7 for seawater?
A: Gr2 for normal seawater/MSF-MED. Gr7 (Pd-added) for hot reducing-acid cleaning or aggressive crevice duty; Gr12 for hot brine >70°C crevice. We advise by medium, not by habit.

Q3: Is seamless mandatory for condensers?
A: Not always. Welded-and-drawn is accepted in many thin-wall seawater HX. Seamless preferred for high-pressure / U-bend critical / thermal-cycle heavy duty. PO spec wins.

Q4: Can you match my existing bundle heat?
A: Send old heat No.; we check live shelf. If unavailable, propose equivalent heat with full 3.1 for QA review before cutting.

Q5: ECT included or extra?
A: Welded tube 100% ECT by default. Seamless ET/hydro per PO NDT matrix — stated in quote, not buried.

Q6: U-bend lead time?
A: Mandrel U-bend quoted per radius + wall; not same-day, but rush schedule negotiable for shutdowns.

Q7: Minimum order?
A: Stock gauges: short runs accepted, no forced full-stick buy. Setup fee shown transparently. Non-stock heat → mill MOQ quoted honest.

Q8: Certificate real 3.1?
A: Mill-issued 3.1 from the original tube mill's independent inspection function. Heat number on tag = cert = crate. Trader-signed "MTC" not passed off as mill 3.1.

Q9: Can you support roller-expansion parameters?
A: We supply annealed dead-soft tube + end prep; torque WPS qualified by your ASME/PED fabricator. We don't issue WPS.

Q10: Sample before bulk retube?
A: 1–2 cut pieces from same heat at courier cost, deductible from PO.

Request a Quote

Email: sales@[yourdomain].com

Send OD × wall × cut length × qty + medium (seawater/brine/acid). Reply within 24 working hours: live heat, EXW/FOB quote, confirmed dispatch date.

About: Baoji Titanium Valley inventory holder and condenser-tube stockist. ASTM B338 Gr2/TA2 seamless & welded-and-drawn tube, annealed, ECT-verified, EN 10204 3.1 heat-traceable, cut-to-length, capped and export-crated. Same-day dispatch on confirmed in-stock orders — built for retubing windows, not paperwork delays.
