Titanium TubeTitanium TubeTitanium Tube

Titanium Tube

SpecificationMaterial Grade:Gr1, Gr2, Gr5`
Applicable StandardStandard:ASTM B338, GB/T 3624`
Material ConditionProduct Type:Seamless & Welded`
Inspection & PackagingDelivery:Same-day shipment for stock`
Reference Price$17.00 – $22.00

Product Description: titanium tube,Grade1 titanium tube,Grade2 titanium tube,Grade5 titanium tube,titanium pipe,Baoji titanium tube stock,titanium tube export

Request a Quote Contact Sales

Product Overview

Overview

We supply Gr1, Gr2, Gr5 seamless and welded titanium tubes located in Baoji, China Titanium Valley. As a professional titanium stockist & supplier, we maintain 80 tons of titanium tubes in stock for fast delivery. We can interpret engineering drawings, provide custom cutting service, fully comply with ASTM B338, ASTM B861, ASME SB338 and GB/T 3624 standards. Full-set export documents and MTC material test certificates are available for each batch, in-stock items support same-day shipment.

Core Specifications

Available Grades Gr1, Gr2, Gr5 (Ti-6Al-4V)
Product Type Seamless Titanium Tube, Welded Titanium Tube
Outer Diameter 3mm‑219mm
Wall Thickness 0.3mm‑20mm
Length Standard length or custom cut per drawings
Surface Condition Pickled, Bright‑annealed, Sandblasted
Applicable Standards ASTM B338, ASTM B861, ASME SB338, GB/T 3624, GB/T 3625
Certificates ISO9001, EN10204 3.1 MTC, third‑party test report available

Key Benefits

  • Superior corrosion resistance against acid, alkali, chloride and seawater media
  • High strength‑to‑weight ratio, low density for lightweight structure design
  • Good thermal conductivity, perfect for heat‑exchange working conditions
  • Excellent weldability and machinability
  • Stable mechanical performance under high‑low temperature environment

Available Grades Description

  • Grade1 (CP Titanium): High ductility and outstanding formability, suitable for severe corrosion environments.
  • Grade2 (CP Titanium): Most widely‑used industrial pure titanium grade, balanced strength & corrosion resistance for chemical and heat‑exchanger equipment.
  • Grade5 (Ti‑6Al‑4V): High‑strength titanium alloy, ideal for high‑pressure structural components.

Titanium Tube Types

Seamless Titanium Tube
Uniform wall thickness, high pressure resistance, excellent mechanical performance. Mainly used for chemical pipeline, high‑pressure heat exchanger, offshore equipment.

Welded Titanium Tube
Cost‑effective solution, available for long‑length and large‑diameter production. Suitable for medium‑pressure corrosion‑resistant piping systems.

Industry Applications

  • Chemical Processing: Corrosion‑resistant process pipelines & heat exchangers
  • Salt‑Lake Lithium Extraction: Brine circulation pipes and evaporator tubes
  • Marine & Offshore Engineering: Seawater cooling pipelines
  • Seawater Desalination: Condenser and heat‑exchange tubing
  • Petrochemical & Pressure Vessel supporting piping

Quality Assurance

Every batch of titanium tubes undergoes strict inspection before shipment:

  • Dimension tolerance inspection
  • Eddy‑current testing (ET)
  • Hydrostatic pressure test
  • Chemical composition & mechanical property testing
  • Material Test Certificate (MTC) supplied for traceability

Our Service Advantages

  • ✅ Large spot inventory: 80 tons titanium tubes in stock
  • ✅ Custom cutting service, cut‑to‑size according to your requirements
  • ✅ Professional drawing interpretation, support non‑standard dimension processing
  • ✅ ISO9001 certified, MTC certificates provided for each shipment
  • ✅ Meet ASTM, ASME and GB international standards
  • ✅ Global export service, same‑day shipment for in‑stock goods

Packaging & Shipment

Export‑standard plywood wooden case packaging. Support sea freight, air freight and international express. We can follow customer special packaging requirements.

FAQ

Q: Can you cut titanium tubes according to my drawing?
A: Yes. Our engineering team can read technical drawings and provide custom cutting and non‑standard processing.

Q: What is your lead‑time for titanium tubes?
A: In‑stock items can be shipped on the same day; custom‑made non‑stock products depend on actual processing requirements.

Q: Can you provide material test reports?
A: Yes, EN10204 3.1 MTC certificates are available for all our titanium tube orders.

If you have technical specifications or project requirements, feel free to send us your inquiry for quotation.

Gr2 welded titanium pipe corrosion resistant

Request a Quote for Titanium, Nickel or Zirconium

Tell us what you need. Send the points below and we reply with live stock status, price and lead time — usually the same day.

Send us these 6 points (or just attach your drawing / old supplier spec)

1 Material grade — Gr2 / Gr5 / Gr7 / Gr12, Ni200 / Ni201 / Monel 400, Zr702…
2 Form — plate / tube / bar / wire / fitting / flange / fastener / equipment
3 Size & tolerance — thickness×width×length / OD×WT / diameter
4 Quantity — kg / pcs / m (small batch and non-standard sizes welcome)
5 Standard — ASTM B265 / B338 / B348, ASME B16.5, EN 1092-1…
6 Application & destination — helps us pick the right grade and certifications

Not sure how to fill this? Send your drawing or an old supplier's specification sheet — we will break it down for you.

Reach us directly

Email: [email protected]

WhatsApp / WeChat:+8618829679311 leave your number on the form

Or use the inquiry form on this page — attach your drawing and we will respond within one business day.

Why buyers come to us

Stock holder in Baoji Titanium Valley with ~800 t inventory · cut-to-size and small batch · drawing-based machining for non-standard parts · we read ASTM / ASME / GB specs · export experience · same-day response on quotes.

Titanium Weight Calculator — Quick Reference

All values use density 4.51 g/cm³ (commercially pure and most Ti alloys). For Gr5 / Ti-6Al-4V (4.43 g/cm³) multiply by 0.982. Figures are theoretical; actual weight varies with tolerance and surface condition.

1. Plate & Sheet — weight per square metre

Formula: kg/m² = thickness(mm) × 4.51

Thickness (mm) 0.5 0.8 1.0 1.5 2.0 3.0 4.0 5.0
kg/m² 2.26 3.61 4.51 6.77 9.02 13.53 18.04 22.55
Thickness (mm) 6.0 8.0 10.0 12.0 15.0 20.0 25.0 30.0
kg/m² 27.06 36.08 45.10 54.12 67.65 90.20 112.75 135.30

Per full sheet: kg = T(mm) × width(mm) × length(mm) × 4.51 ÷ 1,000,000.

2. Round Bar — weight per metre

Formula: kg/m = diameter²(mm) × 0.00354

Diameter (mm) 6 8 10 12 15 20 25 30
kg/m 0.127 0.226 0.354 0.509 0.796 1.415 2.211 3.183
Diameter (mm) 40 50 60 80 100 150 200 —
kg/m 5.659 8.843 12.73 22.64 35.37 79.58 141.48 —

3. Tube / Pipe — weight per metre

Formula: kg/m = (OD − wall)(mm) × wall(mm) × 0.01414

Size (OD × wall, mm) 25.4×1.2 25.4×1.65 25.4×2.0 38×1.5 38×2.0
kg/m 0.411 0.554 0.662 0.775 1.018
Size (OD × wall, mm) 57×2.0 57×3.0 60.3×2.0 89×3.0 114×3.0
kg/m 1.555 2.291 1.647 3.648 4.708

For 114×4.0 mm use 6.222 kg/m. Other walls: apply the formula above.

Need the exact weight for your size?

Send us your grade, dimensions and quantity on our inquiry page — we calculate it free of charge, usually within one business day, and quote against our stock of about 800 tonnes in Baoji Titanium Valley.

Request a Quote

Cut-to-size • drawings accepted • ASTM / ASME / GB • export packing • same-day dispatch on stock items.
