Gr2 Titanium Plate ASTM B265 — 0.5-60mm Thick, Cut to Size

Gr2 Titanium Plate supplied to ASTM B265, available from 0.5 mm to 60 mm thick and up to 2000 mm wide, cut to size to your drawing. We hold 300 tonnes of Titanium Plate in stock at our Baoji warehouse in China's Titanium Valley, ready for immediate shipment. Gr1, Gr3, Gr5 (TC4), Gr7, Gr9 and Gr12 are also available in standard and non-standard sizes, with EN 10204 3.1 certification on every order. For current market levels, see our titanium price index.

Specifications

Chemical Composition (ASTM B265, weight %)

Mechanical Properties (ASTM B265, room temperature)

How to Select the Right Grade

Grade selection is usually driven by the service medium rather than by mechanical strength alone:

• Gr1 — highest formability and ductility. Suited to deep drawing, complex forming and light corrosive duty.
• Gr2 — the most widely used commercial pure grade. Balanced corrosion resistance and mechanical properties, and the default choice for chemical process equipment, heat exchanger tube sheets and vessel linings.
• Gr3 / Gr4 — higher strength commercial pure grades for pressure-bearing components where forming requirements are moderate.
• Gr5 (TC4 / Ti-6Al-4V) — aerospace-grade alloy, roughly twice the strength of Gr2. Selected where high specific strength matters, and for medical implant applications in ELI form (Gr23).
• Gr7 — palladium-bearing grade with markedly improved resistance to reducing acids and crevice corrosion.
• Gr12 — molybdenum-nickel grade with excellent resistance to hot chloride and high-temperature brine; common in seawater and concentrated salt service.

If you are unsure which grade fits your medium, send us the operating temperature, medium composition and concentration, and we will recommend a grade before quotation.

Manufacturing Route and Surface Finish

Plate is produced from vacuum-melted ingot, forged and then hot rolled to the required thickness, followed by annealing, levelling and surface treatment. Thin gauges below roughly 4 mm are normally cold rolled and annealed to achieve flatness and surface quality. We supply pickled, sandblasted, ground or polished finishes, and can hold tighter flatness or thickness tolerances than the standard where the application requires it.

Applications

• Chemical processing — reactor vessels, towers, storage tank linings, heat exchanger tube sheets, agitator components
• Seawater and marine — desalination plant, shipboard piping and seawater cooling systems
• Power generation — condenser tube sheets, flue gas desulphurisation systems
• Electroplating and electrolysis — electrolytic cells, electrode plates, anode baskets, plating racks
• Medical — implantable devices and surgical instruments in Gr5 ELI / Gr23
• Aerospace — structural components, brackets and skin panels in Gr5
• Environmental — wastewater treatment, exhaust gas scrubbers

Quality Control and Certification

• Spectrometric chemical analysis with full heat-number traceability
• Tensile and hardness testing to ASTM B265, with certified mill test report
• Ultrasonic testing (UT) available to ASTM B265 or your specification
• Dimensional and flatness inspection before packing
• PMI / XRF positive material identification available on request
• Certification: EN 10204 3.1 as standard, 3.2 available with third-party witness

Stock, Lead Time and Packaging

We hold 300 tonnes of Titanium Plate in stock at Baoji, covering common grades and thicknesses in standard widths. Holding stock allows us to quote against today's material position rather than against a future production slot, and to ship stock sizes in as little as 3–5 days. Cut-to-size, non-standard widths and special tolerances are normally 15–30 days.

Plate is packed on fumigated wooden pallets or in export-grade wooden crates, with interleaving paper or film between sheets, edge protection and full seaworthy wrapping. Surface protection matters — a scratched sealing or cladding face is a common cause of rejection on arrival.

Frequently Asked Questions

What is the minimum order quantity?
From a single sheet. We accept sample orders and small-batch orders, which is often the practical way to qualify a new supplier before committing to a full project quantity.

Can you cut plate to size?
Yes. We cut to your drawing by plasma, waterjet or shearing depending on thickness and edge quality required, and can supply machined or bevelled edges.

What thickness can you supply from stock?
Common stock thicknesses run from 0.5 mm to 60 mm in Gr2 and Gr5, subject to availability at the time of enquiry. Send us your required grade and thickness and we will confirm current stock.

Do you supply material certificates?
EN 10204 3.1 is supplied as standard with heat-number traceability. EN 10204 3.2 with third-party witness can be arranged where the project specification requires it.

Can you supply plate to a non-Chinese standard?
Yes. We routinely supply to ASTM, ASME, AMS, DIN and JIS requirements. Where a project calls for dual certification, we will confirm the applicable clauses before production.

Request a Quotation

Send us the grade or applicable standard, thickness, width and length, quantity, surface finish, and any inspection or certification requirements. We will confirm current stock against your specification and return a firm FOB quotation, usually within 24 hours.
