Small Diameter Titanium Capillary Tube in Stock \| Gr2/TA2 Seamless, ASTM B338/B861, Cut-to-Length

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Small Diameter Titanium Capillary Tube in Stock | Gr2/TA2 Seamless, OD 0.5–8mm

Meta Description: Small diameter titanium capillary tube in stock from Baoji. Gr2/TA2 seamless, OD 0.5–8mm, ASTM B338/B861, cut-to-length, deburred ID/OD, EN 10204 3.1, clean-pack for instrument & medical R&D. Quote in 24h.

Overview — A Capillary Tube Is Not "A Small Pipe"

When OD drops below 3mm, the game changes. It stops being about pressure rating alone and starts being about what touches the fluid: ID roughness, concentricity, end burr, dead volume, ion leaching. A 0.5mm titanium capillary in an HPLC line is closer to an optical part than to a heat-exchanger tube.

We keep Gr2/TA2 small-diameter seamless capillary on rotating stock — common ODs (0.5 / 0.8 / 1.0 / 1.5 / 2.0 / 3.0 / 4.0mm) pulled, cut, deburred, capped, certed. Not "all sizes forever in stock" — the sub-0.5mm and mirror-ID jobs are project-drawn, and we say so before the PI.

What "In Stock" Means Here (Honest Version)

No "everything ready" bluff. We tell you the heat number, then cut.

Why Titanium Capillary, Not 316L or PEEK

Titanium is the middle road: polymer-clean, steel-strong.

Stock Size Map (Gr2/TA2)

Tolerance (precision draw): OD ±0.01–0.03mm, wall ±0.01mm on request, cut length ±0.05–0.1mm standard (tighter = machining quote).

Technical Baseline (Gr2 / TA2, Annealed)

End & Surface Handling (Where Cheap Tubes Fail)

• Double deburr: ID + OD both dressed — no whisker burr to shed particles
• Square cut: low-vibration cut, no ovality introduced
• Cap both ends: PE plug / silicone cap, keeps ID clean in transit
• Surface: bright-annealed default for instrument use; pickled for industrial
• Mirror ID: additional mandrel-polish pass, Ra<0.4µm, project lead time
• Clean pack: dust-free bag + PVC straight barrel / PP tube, then crate

Cleanliness & Certification

• EN 10204 Type 3.1 MTC — issued by the original tube mill's independent inspection function, heat-matched
• Actual chemistry (Fe/O/H/N) + tensile on cert; O-value printed, not just "pass"
• Dimensional report: OD / wall / ID / length / straightness
• ECT on welded; seamless per PO NDT matrix (UT/ECT)
• Cleanliness decl. (oil-free, particle count) on request — not a "sterile" claim
• 3.2 (SGS/BV/TÜV) at buyer cost

We do not self-declare "ISO 13485 implant-approved." Medical acceptance is your QA/MRO call; we supply traceable material + clean process data.

Where These Tubes Actually Go

• HPLC / UHPLC fluid paths (kill peak tailing & carryover)
• Medical R&D: biopsy-needle cannulae, catheter liners, drug-delivery micro-lines
• Dental implant drainage / marker components (non-implanted use unless graded)
• Pressure sensors, thermocouple sheaths, micro-probes
• Semiconductor ultra-clean gas sampling (bright ID)
• Aerospace mini hydraulic / fuel sense lines (Gr9 on request)
• Corrosion sample loops in lab reactors

Cut-to-Length for Micro Tubes

1. PO: OD×wall×len×qty + end condition + pack grade
2. Pull tagged heat; log heat before cut
3. Low-vibration cut → ID/OD deburr → straightness check
4. Cap + PE sleeve + clean bag
5. MTC 3.1 + dim report; QA cross-check tag=cert=crate
6. Dispatch per stock workflow (confirmed in-stock, before 3 PM China time)

Packaging (Micro-Grade, Not Barrel Dump)

• Single tube in PVC straight barrel or PP rig
• Dust-free PE bag, desiccant for long-sea
• Foam cradle inside ISPM-15 crate
• No carbon-steel contact, no shop-floor dust
• Label: grade / OD×WT / len / heat No. / PO ref

Enquiry Template (Copy-Paste)

Grade: Gr2 / TA2 / Gr1 / Gr9 / Gr23 ___
Standard: ASTM B338 / B861 ___
OD × Wall: ___ mm × ___ mm
Length: ___ mm × ___ pcs
ID roughness: as-drawn / Ra<0.4µm (mirror) End: plain square / deburr both sides / capped Clean pack: dust-free bag + PVC barrel (yes/no) NDT: ECT / UT / dim report / 3.1 or 3.2 Use: HPLC / medical R&D / sensor / semi-gas Heat: any in-stock / match previous ___ Port: ___ (FOB Shanghai default)

FAQ — Small Diameter Titanium Capillary

Q1: What's truly on the shelf?
A: Gr2/TA2 OD 0.5–8mm common walls rotate in stock. Sub-0.5mm or mirror-ID = draw-to-order; we confirm heat + lead before PI.

Q2: Can you control ID roughness?
A: As-drawn Ra ~0.4–0.8µm standard; mirror pass Ra<0.4µm on project basis. Concentricity report available.

Q3: Will burrs shed particles?
A: Double deburr ID+OD by default. If you need burr-free cert level, specify "no-touch ID inspection + clean bench" in PO.

Q4: Is it sterile / implant-grade?
A: Supplied clean (oil-free, degreased, DI-rinsed), not sterilized. Implant acceptance = your QA/MRO per applicable spec; we provide traceable material + process records.

Q5: HPLC replacement for PEEK?
A: Yes for high-pressure organic solvents. Give us current OD/ID and fitting type; we match flow path, not just outer size.

Q6: Length tolerance?
A: Standard cut ±0.05–0.1mm; tighter (±0.02mm) by machining quote — micro tubes don't get "shear ±0.5mm" treatment.

Q7: Gr9 capillary?
A: Available on heat-confirm; CWSR micro-draw lead time quoted honest, not "same shelf as Gr2."

Q8: How is it packed?
A: PVC barrel / PP straight rig + dust-free bag + foam cradle crate. No loose rattling in a big box.

Q9: Certificate real 3.1?
A: Mill-issued 3.1 from original tube mill's independent inspection function. Heat tag = MTC = crate label.

Q10: Sample for fit-up?
A: 2–3 cut pieces from same heat at courier cost, deductible from PO.

Request a Quote

Email: sales@[yourdomain].com

Send OD×wall×length×qty + application (HPLC / medical R&D / sensor). Reply within 24 working hours: live heat, cut quote, cleanliness scope, dispatch date.

About: Baoji Titanium Valley inventory holder. Small-diameter titanium capillary tube — Gr2/TA2 seamless, OD 0.5–8mm rotating stock, ASTM B338/B861, multi-pass drawn, double-deburred, clean-packed, EN 10204 3.1 heat-traceable. Sub-0.5mm and mirror-ID run as project draws. We sell the inside of the tube, not just the outside.
