Gr1 Gr2 Gr5 Gr7 Small Batch Titanium Fittings With Zero Cutting

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Small Batch Titanium Fittings, Zero Cutting | WPT2/WPT5, ASTM B363 + ASME B16.9, As-Stock, No Re-Cut

Meta Description: Small batch titanium butt weld fittings with zero cutting — ASTM B363 WPT2/WPT5, ASME B16.9 standard dimensions, dispatched as-annealed from rotating stock, no re-cut, no hand-ground bevel. Same heat, same MTC 3.1, same export pack as full lots.

What "Zero Cutting" Means Here

Not a marketing word — a process promise:

• Piece ships in its standard ASME B16.9 geometry — no tangent trim, no leg cut, no angle re-form
• Bevel is the original formed bevel, machined to 37.5°±2.5° at forming stage — not re-ground after a cut
• Annealed before dispatch, pickled, bevel-capped — exactly as the rotating heat leaves the line
• Heat number on tag = heat number on MTC = heat number on PL

If your job uses standard center-to-face (LR 1.5D / SR 1.0D), you do not pay for cut labor, and you do not inherit a re-bevel risk.

Who This Page Is For

• Shutdown spares: 2 elbows + 1 tee, need them Thursday
• Skid prototype / FAT loop: small qty, full cert
• First-time titanium buyer: trial lot before project award
• EPC vendor qualification: sample pieces, audit-ready
• Distributor top-up: refill standard SKUs without a tonnage PO

Small Batch ≠ Lower Standard

One piece or one pallet — the metallurgy does not change with the invoice.

Stock Reality (honest)

Large bore (NPS6+) = project heat / welded route — scheduled, not "shelf zero-cut". We say so in the first reply.

Why Zero-Cut Sometimes Beats Cut-to-Length

• No saw kerf, no heat-affected trim edge
• No re-bevel variance from hand finishing
• Fastest dispatch — no secondary operation queue
• Cheapest certifiable option for standard layouts
• Field welder gets a fitting identical to the P&ID symbol

Standards & End Prep

• Material: ASTM B363 / ASME SB363 (WPTx)
• Dimensions: ASME B16.9; stub end MSS SP-43
• Bevel: ASME B16.25, 37.5°±2.5°, plastic cap
• Surface: pickled descale, argon-clean ends, no steel contact
• Annealed after forming; stress-relief per code on cold-formed pieces

Traceability (same as full lot)

1. Ingot → heat No.
2. Formed blank → etched heat
3. Annealed + pickled → re-tag, no re-cut
4. MTC 3.1: measured interstitials + tensile, heat-to-ingot
5. Tag = MTC = PL (three-way match)

Inspection on Small Batch

• OD / wall / ovality / center-to-face per B16.9
• Visual + PT on body
• PMI spot (Gr7 Pd check on request)
• Dimensional report per piece on request
• Pre-ship photo: tag + bevel cap + crate

Export Docs (no scale-down for small qty)

• CI + PL (heat-referenced)
• EN 10204 3.1 (3.2 SGS/BV/TÜV PO-fronted)
• COO on request
• HS reference: WCO 6-digit 8108.90 base; destination sub-heading via broker
• ISPM-15 case, desiccant, bevel cap

RFQ Template (copy-paste)

Fitting: 90LR elbow / tee / conc reducer / stub end ___
Grade: WPT2 / WPT5 / WPT7 / WPT12 ___
NPS × SCH: ___ (DN ___)
Qty: ___ pcs (zero-cut, standard B16.9)
Bevel: standard 37.5° / confirm ___
Cert: 3.1 / 3.2 (TPI ___)
Incoterm: EXW Baoji / FOB Shanghai / DAP ___
Destination: ___

FAQ — Small Batch Titanium Fittings, Zero Cutting

Q1: Is "zero cutting" the same as "stock item"?
A: For standard B16.9 sizes on rotating heat — yes. It ships as-formed, no tangent trim, no re-bevel.

Q2: Does small qty get a real MTC 3.1?
A: Same 3.1 scope as a full heat. Measured chemistry, heat-to-ingot, QA signature.

Q3: Minimum order?
A: Trial qty handled (spares/prototype). No "tonnage-only" gate for standard SKUs.

Q4: Can I mix elbow + tee + reducer in one small crate?
A: Yes. Each piece tagged, one cert pouch, one PL.

Q5: Is the bevel hand-ground after cutting?
A: No — that's the point of zero-cut. Original machine bevel, capped, argon-clean.

Q6: What if my layout needs a custom tangent?
A: Then it's a cut-to-spec job (separate route). We tell you before PI — no silent upsell.

Q7: Gr5 small batch?
A: Project heat, quoted pre-PI. Same no-cut discipline; aviation claim only with PO-named AMS.

Q8: Dispatch window?
A: Rotating WPT2 small bore → pack same working week after lot confirm. Gr5/project heat → schedule quoted.

Q9: HS code?
A: WCO base 8108.90; country sub-heading via broker. Process statement supplied.

Q10: Will cert survive auditor review?
A: Tag=MTC=PL three-way match + measured interstitials + QA sign-off — the default, not an add-on.

Request a Quote

Email: sales@[yourdomain].com

Send grade + NPS×SCH + qty + "zero-cut standard B16.9". Reply in 24h: live heat No., EXW/FOB price, MTC type, dispatch date.

About: Baoji Titanium Valley small-batch line — ASTM B363 WPT2/WPT5 butt weld fittings, ASME B16.9, dispatched as-annealed, zero re-cut, original machine bevel, heat-traceable, EN 10204 3.1. Small qty, full documentation: no trimmed blank, no hand-ground bevel, no cert downgrade. Lot confirmed before PI.
