Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Titanium Flange with RT Test Report | ASTM B381 Gr2/Gr5, Weld Radiography + UT/PT, EN 10204 3.1

Meta Description: Titanium Flanges with RT test report — ASTM B381 Gr2/Gr5/Gr7 forged, ASME B16.5, weld radiography per ASME Section V, UT on forging + PT on face default, RT on specified welds. Titanium/aluminium IQI, RT report bundled with EN 10204 3.1.

RT on a Flange — What It Actually Covers

A common mistake: "send RT report for the flange" — but a forged flange body is not a weld. Correct scope:

• Forging body → UT (volumetric) + PT (surface) is the standard route
• Welded joints (nozzle-to-shell, flange-to-pipe shop weld, repair weld) → RT or UT per ITP
• RT report covers the weld seam, not the whole forged disc
• RT + UT are complementary: RT sees volumetric defects (porosity/slag), UT sees tight cracks/orientation

So "flange with RT" = RT on the declared weld, UT on the forging, PT on machined faces — packaged as one NDE dossier.

When RT Is Required (not by default on every flange)

• Nozzle attachment weld on pressure vessel (per EN 13445-11 / ASME VIII ITP)
• Shop-welded flange-to-pipe or flange-to-stub permanent joint
• Repair weld after forging/processing defect removal
• Class/code project mandates RT% in ITP (Group 1 = 100% RT/UT + PT)
• Third-party (SGS/BV/TÜV/DNV) witness point at RT

If no weld and no ITP clause → UT+PT+3.1 is the honest default. We don't pad a fake "full-flange RT" line.

RT Technique for Titanium (the detail auditors check)

• Per ASME Section V Art.2 / ASTM E94 / E1742 (as specified)
• X-ray source; sensitivity target per code (e.g. 2-2T wire IQI where applicable)
• Titanium or aluminium Image Quality Indicator (IQI) — not steel IQI (Ti absorbs less, steel IQI lies)
• Argon-shielded weld zone colour acceptance: silver/straw pass; blue/purple/grey reject
• Film or CR/DR digital; DICONDE/PDF film + readable IQI value on report
• Acceptance level: ASME B31.3 / EN 13445-5 Table 8.6 / client ITP

NDE Dossier Shipped With the Flange

1. EN 10204 3.1 MTC — heat chemistry + tensile, QA-signed
2. UT report — forging volumetric, ASNT Level II, technique + calibration block
3. PT report — machined face, colour coupon reference
4. RT report (where PO-scoped): seam ID, % covered, IQI type, sensitivity, film/CR ref, accept/reject
5. Weld map / heat linkage (if shop weld included)
6. 3.2 countersign by TPI if PO-fronted

Default vs PO-Scoped NDE

Grade & Standard Scope

• ASTM B381 F-2 (Gr2/R50400/3.7035), F-5 (Gr5/R56400), F-7 (Gr7/Pd)
• ASME B16.5 (WN/SO/Blind), B16.47 large bore, EN 1092-1 on request
• Closed-die forged, annealed, CNC, pickle, face-protected
• Heat No. etched pre/post machine — parent = finished

RFQ Template (RT scope written correctly)

Flange: WN / Blind / SO ___
Grade: Gr2 (F-2/R50400) / Gr5 / Gr7 ___
Standard/Class: B16.5 300# / EN1092 PN16 ___
NPS×SCH: ___
Shop weld included? Y/N (nozzle attach / stub / pipe tail) ___
RT scope: 100% / 25% / repair only ___
IQI: Ti / Al (specify) ___
Accept basis: ASME B31.3 / EN13445-5 Table 8.6 / client ITP ___
UT: forging 100% Y/N ___   PT: face Y/N ___
Cert: 3.1 / 3.2 (TPI ___)
Incoterm: EXW Baoji / FOB Shanghai / DAP ___

FAQ — Titanium Flange with RT Test Report

Q1: Do you RT the whole forged flange?
A: No — forging body uses UT+PT. RT applies to welded seams (nozzle/shop weld/repair), per ITP.

Q2: Can RT replace UT?
A: Not ideally. RT catches porosity/slag; UT catches tight cracks/orientation. Critical joints often run both.

Q3: Why titanium IQI, not steel?
A: Ti X-ray absorption is lower than steel; steel IQI overstates sensitivity. Ti/Al IQI gives true image quality.

Q4: Is RT report part of MTC 3.1?
A: Separate NDE attachment bundled with 3.1 in the cert dossier. 3.1 = material; RT = weld integrity.

Q5: 100% RT on nozzle weld?
A: Yes when ITP says Group 1 / fatigue / critical service. State % and accept level at PO.

Q6: Gr5 (TC4) RT different?
A: Same RT logic; ERTi-5 weld, argon both sides, colour acceptance silver/straw.

Q7: 3.2 with RT witness?
A: TPI named at PO, witnesses RT. Cannot back-build from 3.1 after shot.

Q8: Hydro test on flange only?
A: No — hydro is vessel/line scope. Flange ships with NDE + 3.1; hydro done at assembly.

Q9: RT film or digital?
A: CR/DR digital default; film on request. IQI value + technique sheet in report either way.

Q10: HS code?
A: WCO 6-digit 8108.90 base; destination sub-heading via broker.

Request a Quote

Email: sales@[yourdomain].com

Send flange spec + "RT on which weld, what %, IQI type, accept basis". Reply in 24h: NDE plan, EXW/FOB price, MTC type, dispatch window.

About: Baoji Titanium Valley RT-scope flange line — ASTM B381 Gr2/Gr5/Gr7, ASME B16.5, closed-die forged, UT on body + PT on face default, RT on declared welds per ASME Section V with Ti/Al IQI. RT report bundled with EN 10204 3.1 — no phantom "full-disc radiography", no steel IQI, no cert downgrade. Lot confirmed before PI; tag = MTC = PL = weld map.
