Gr2 seamless titanium tube stock for heat exchanger

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Gr2 Seamless Titanium Tube Stock for Heat Exchanger | ASTM B338 Cut-to-Length

Meta Description: Gr2 seamless titanium tube stock for heat exchanger from Baoji. ASTM B338, OD 6–114mm, cut-to-length, 100% eddy current + hydrostatic test, MTC EN 10204 3.1, same-day dispatch on confirmed in-stock orders. Quote within 24h.

Overview

We are a Baoji-based titanium inventory holder and supplier with 800 tons total titanium stock, including around 80 tons of titanium tube across seamless and welded sizes. For heat exchanger builders, Gr2 (UNS R50400) seamless tube is a standing stock line — not a full-mill made-to-order item. This page covers what we actually hold, why Gr2 is the default choice for shell-and-tube / condenser / desalination bundles, how we test and cut, and exactly what to send us for a quote. Written for procurement engineers and fabricators, not for ad copy.

Why Gr2 Seamless Tube for Heat Exchangers

• Seamless = no weld line: uniform wall, no longitudinal weld defect, better for high-cycle thermal stress and pressure duty
• Chloride immunity: stable TiO₂ film resists seawater, brine, wet chlorine, hypochlorite — no pitting/crevice corrosion like 316L
• Lightweight: density 4.51 g/cm³, ~40% lighter than stainless — lower support load on tube sheets
• Low fouling: smooth surface, less scaling, stable heat-transfer coefficient over years
• Weldable: GTAW/TIG with pure argon backing; compatible with Gr2 tube sheet and baffles
• Service life: 15–25 years typical in seawater cooling; longer with proper velocity control

Stock Snapshot (Honest, Rotating)

Standard mother lengths 4m / 6m. Cut-to-length from 50mm upward. Live meterage confirmed before PI.

Technical Parameters (Gr2 / TA2)

Testing & Quality (Every Heat)

• 100% eddy current test (ET) per ASTM B338 / EN 10246
• Hydrostatic or pneumatic pressure test
• Ultrasonic wall-thickness check on sampled lots
• Chemical analysis (Fe/O/N/C/H) vs heat certificate
• Flaring / flattening test on request
• MTC EN 10204 3.1 with heat-number traceability
• Third-party (SGS / BV / TUV) at buyer cost

Cut-to-Length & End Prep

• Plain end (square cut, deburred) — default
• Beveled end for orbital welding
• U-tube bending per radius drawing (offered via partner shop)
• Length tolerance: ±0.5mm on fixed lengths
• End plastic caps + film sleeve before packing

Typical Heat Exchanger Uses

Grade Selection Note

• Gr2: default for seawater, chloride, oxidizing acid
• Gr1: higher purity, deeper drawing, lower strength — for forming-intensive parts
• Gr7 (Pd): reducing-acid / high-temperature acid duty
• Gr9 (Ti-3Al-2.5V): higher strength, thinner wall allowed
• Gr12: reducing/oxidizing mixed media

Send process conditions (medium, temp, velocity, chloride ppm); we confirm grade rather than auto-upgrade — no silent substitution.

Export Packaging

• Each tube sleeved in PE film + plastic end caps
• Bundled with foam separation, no carbon-steel contact
• Fumigated wooden crate / plywood case with steel strapping
• Moisture-barrier liner for long-sea shipment
• Tag: grade, heat number, OD×WT, length, PO ref
• Coils (if supplied) on wooden reel with end protection

Why Buy From Stock (Not Mill)

• No full-coil / full-mother-tube minimum forced
• Cut exact bundle length → less scrap at fab shop
• Same-day dispatch on confirmed in-stock orders (before 3 PM China time)
• One heat number per bundle, MTC cross-checked before crate close
• Prototype 10m or project 2km — same process

FAQ — Gr2 Seamless Tube for HX

Q1: Is your Gr2 tube truly seamless?
A: Yes. Cold-pilgered seamless mother tube, annealed, no longitudinal weld. ET + hydrostatic tested.

Q2: What OD/Wall do you keep for 1" bundles?
A: 25.4×1.2 / 1.5 / 2.0mm are core stock. Other walls cut from mother tube or sourced from partner mill with lead-time quote.

Q3: Can you supply U-tubes bent to radius?
A: Yes via partner bending shop — send bend radius + leg length; we supply straight stock pre-tested, then bend, then re-inspect.

Q4: Velocity limit for seawater?
A: Typical design 1.5–2.5 m/s to avoid stagnation fouling; we advise per project, not a fixed marketing number.

Q5: Do you provide passivation after cutting?
A: Pickled/bright annealed is default (self-passivating). Additional nitric passivation available on request for pharma/food.

Q6: MOQ?
A: No hard MOQ. One length accepted for prototype; bulk priced by kg.

Q7: How is traceability kept after cutting?
A: Heat-number tag travels with bundle from stock to cut to crate; MTC heat number = physical tag.

Q8: Can you match ASME U-stamp documentation?
A: We supply MTC 3.1 + material docs; final U-stamp is issued by the fabricator/ASME shop. We support their dossier.

Q9: Lead time for cut-to-length?
A: In-stock OD: cut + test + pack 1–2 working days. Non-stock wall: confirm replenishment lead at enquiry.

Q10: Sample?
A: 300mm coupon from same heat, courier at cost, deductible from bulk PO.

Request a Quote

Send to sales@[yourdomain].com:

1. Grade: Gr2 / TA2 (or Gr7/Gr9 if medium demands)
2. OD × Wall: e.g. 25.4×1.5mm
3. Quantity: meters / total kg / bundle count
4. Length per piece + total pieces
5. Surface: pickled / bright annealed
6. End: plain / beveled
7. Standard: ASTM B338 / GB
8. Docs: MTC 3.1 + COO + (SGS/BV if needed)
9. Destination port

Reply within 24 working hours with live stock check + EXW/FOB quote.

About: Baoji Titanium Valley inventory holder. ~80 tons titanium tube within 800-ton total stock. Gr2 seamless ASTM B338 tube for heat exchanger, condenser, desalination. Cut-to-length, ET+hydrostatic tested, MTC EN 10204 3.1, export crate, same-day dispatch on confirmed in-stock orders.
