Titanium Blind & Weld Neck Flange Supplier

Specification	We supply titanium blind flange and weld neck flange in Gr1, Gr2, Gr5 and Gr7 grades. WN flanges feature tapered hub for high-pressure welding, while blind flanges serve for pipeline closure, both sup
Applicable Standard	Our titanium blind flanges and weld neck flanges are produced to ASME B16.5 and ASTM B381. Every batch passes dimensional and material inspection, with official MTC provided for pressure vessel and pi
Material Condition	Weld neck and blind titanium flanges withstand chloride, brine and acidic corrosion. WN type minimizes stress concentration at weld joints; blind flanges deliver reliable sealing for isolation, test a
Inspection & Packaging	As a professional flange supplier, we stock regular class sizes of these two flange types. Stock items can be shipped within 3–7 days. We provide seaworthy export packing, full documents and flange se
Reference Price	$10.00 – $15.00

Product Description: Titanium weld neck + blind flange supplier — ASTM B381 F-2 (WPT2/R50400/3.7035), ASME B16.5, Class 150–600, RF/FF/RTJ, closed-die forged + CNC machined, pickled, heat-traceable, EN 10204 3.1. WN for h

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Titanium Weld Neck & Blind Flange Supplier | ASTM B381 F-2 (WPT2/R50400), ANSI B16.5, Forged + CNC, MTC 3.1

Meta Description: Titanium weld neck + blind flange supplier — ASTM B381 F-2 (WPT2/R50400/3.7035), ASME B16.5, Class 150–600, RF/FF/RTJ, closed-die forged + CNC machined, pickled, heat-traceable, EN 10204 3.1. WN for high-pressure butt-weld lines; blind for end closure/test ports.

WN vs Blind — Which One Do You Actually Need?

Type	Job on site	When to specify
Weld Neck (WNRF)	Butt-welds to pipe via long tapered hub	High pressure, thermal cycling, fatigue, radiographic weld, Class 300/600+
Blind (BLRF)	Seals pipe end / vessel nozzle / test port	Line termination, hydrotest blind, maintenance isolation, spare closure

They are not interchangeable. WN carries the weld; blind carries the pressure at a dead end. Quoting "one flange" without type = quoting blind.

Grade Identity (write all four on the tag)

Gr2 = CP Titanium Grade 2
Forging: ASTM B381 F-2 | ASME SB381
Fitting logic: WPT2 (B363 family)
UNS R50400 | W.-Nr. 3.7035

Also supply Gr5 (R56400), Gr7 (Pd), Gr12 on PO. Chemistry confirms grade — not the abbreviation.

Specification Scope

Standard: ASME/ANSI B16.5 (NPS 1/2–24); B16.47 Series A for large bore
Type: WN / Blind (SO/LJ/SW on request)
Class: 150 / 300 / 600 rotating; 900–2500 forged to PO
Face: RF default; FF / RTJ groove machined to B16.5
Bore: matched to SCH 5S/10S/40S pipe
Process: closed-die forge → anneal → CNC turn → pickle → etch tag

Why Forged, Not Plate-Cut

Closed-die forging refines grain along the hub — no cast porosity, no plate shear weakness
Annealed alpha structure restored, interstitials controlled
CNC hub taper + bolt-circle pitch to B16.5, not "close enough"
Pressure service = forged B381, always

Stock Reality (honest)

Type	NPS	Class	Status
WNRF	1–6 (DN25–150)	150/300/600	Rotating heat, lot confirmed pre-PI
BLRF	1/2–8 (DN15–200)	150/300	Rotating forged blank + machined
NPS 10–24 / Class 900+	large bore	project	Forged to PO, schedule quoted

"Stock" = confirmed heat + CNC-ready + MTC draft. Not "every class every face same-day".

Where They Go

WN: seawater pump suction/discharge, desalination channel, heat-exchanger nozzle, high-pressure chemical loop
Blind: line end cap, hydrostatic test blind, spare nozzle closure, spectacle blind companion
Both: chlor-alkali, RO reject, wet chlorine, nitric (oxidizing) service

When to Upgrade From Gr2

Hot crevice brine >~80°C → Gr12 or Gr7
Reducing-acid excursion → Gr7 (Pd by chemistry)
High strength / low weight → Gr5 (WPS-matched, not corrosion-default)
HF / dry chlorine / red fuming nitric → titanium excluded

Inspection & Cert

UT on forging, PT on machined face
PMI/XRF grade verification (Gr7 Pd by chem, not label)
Dimensional: OD / bolt circle / hub taper / bore / RF height per B16.5
EN 10204 3.1: measured O/H/N/C/Fe + tensile, heat-to-ingot, QA-signed
3.2 (SGS/BV/TÜV/DNV) PO-fronted — not back-built after shipment

Export Docs & Pack

CI + PL (heat-referenced)
MTC 3.1 + UT/PT summary + dimensional report
COO on request
HS reference: WCO 6-digit 8108.90 base; destination sub-heading via broker
ISPM-15 case, RF face foam-protected, bolt holes oil-free

RFQ Template (copy-paste)

Type: WN / Blind ___
Standard: ASME B16.5
Grade: Gr2 (F-2 / WPT2 / R50400) / Gr5 / Gr7 / Gr12 ___
NPS × SCH (bore): ___ (DN ___)
Class: 150 / 300 / 600 / ___
Face: RF / FF / RTJ ___
Qty: ___ pcs
Cert: 3.1 / 3.2 (TPI ___)
Incoterm: EXW Baoji / FOB Shanghai / DAP ___
Destination: ___

FAQ — Titanium WN & Blind Flange Supplier

Q1: WN and blind — same price logic?
A: No. WN uses more forge stock + hub machining; blind is shorter cycle. Quote by type, not by "flange".

Q2: Is Gr2 enough for seawater?
A: Ambient–moderate T, yes. Hot concentrated brine crevice → Gr7/Gr12 review first.

Q3: Forged or cast?
A: Closed-die forged B381. No cast pressure flange.

Q4: RTJ available?
A: Yes — groove machined to B16.5, common at Class 600+.

Q5: Can WN bore match SCH 5S?
A: Yes — bore machined to pipe wall; state SCH on RFQ, don't assume STD.

Q6: Blind as hydrotest blind?
A: Standard use. Confirm class + bolting pattern; thickness per B16.5.

Q7: Large bore 12–24"?
A: Forged to PO from project heat, B16.47 option, RT per PO.

Q8: MTC real values?
A: 3.1, measured interstitials + tensile, heat-to-ingot, QA sign-off.

Q9: 3.2 possible?
A: TPI named at PO stage; cannot be retro-built from 3.1.

Q10: HS code?
A: WCO base 8108.90; country sub-heading via broker. Process statement supplied.

Request a Quote

Email: sales@[yourdomain].com

Send type + NPS×SCH + Class + face + qty. Reply in 24h: live heat status, EXW/FOB price, MTC type, dispatch window.

About: Baoji Titanium Valley flange line — ASTM B381 F-2 (WPT2/R50400/3.7035) weld neck + blind flanges, ASME B16.5, closed-die forged + CNC machined, pickled, face-protected, heat-traceable, EN 10204 3.1. WN for butt-weld pressure lines; blind for closure/test ports. No cast-as-forged, no grade relabel, no cert downgrade. Lot confirmed before PI; tag = MTC = PL.

Gr2 titanium WNRF flange B16.5 Class300 forged B381 F-2 Baoji / BLRF R50400 flange MTC 3.1 export pack face protected
