Gr17 Titanium Wire ASTM B863 Low-Oxygen Ti-0.04~0.08Pd for Mild Chloride Corrosion

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Overview

We supply Gr17 Ti-0.04~0.08Pd Titanium Alloy Wire complying with ASTM B863 located in Baoji, China Titanium Valley. As a professional titanium inventory supplier, Gr17 titanium wire is stocked alongside other grades within our total 50 tons titanium wire inventory. We can interpret seawater and mild corrosive medium equipment drawings, provide custom cutting service, fully comply with ASTM B863 standards. Full-set export documents and EN10204 3.1 MTC material test certificates are available for each batch, qualified in-stock items support same-day shipment.

Core Specifications

Available Grade	Gr17 (Ti-0.04~0.08Pd, low oxygen Grade1 Ti base)
Product Type	Low Oxygen Low Pd Alloy Wire / Mild Chloride Corrosion Resistant Wire
Diameter Range	0.4mm‑4.0mm
Supply Form	Spool coil or cut straight wire per customer drawing
Surface Condition	Cold drawn, annealed, pickled surface; bright polished optional
Applicable Standards	ASTM B863
Certificates	ISO9001, EN10204 3.1 MTC, dimensional inspection report available

Key Benefits

• Low oxygen Gr1 substrate, ultra-high ductility and low residual stress compared with Gr16
• Good resistance to mild chloride crevice corrosion, low palladium content controls material cost
• Soft material for deep bending, weaving into fine filter mesh and precision hanging assemblies
• Minimal impurity release, suitable for brine, seawater and low-contamination requirement systems
• Reliable continuous operation in coastal, desalination and mild hydrometallurgy environments

Grade Description

Gr17 Ti-0.04~0.08Pd titanium wire is defined under ASTM B863. It adopts low-oxygen Grade1 pure titanium as base with trace palladium addition to improve crevice corrosion resistance. Gr17 differs from Gr16: Gr16 uses standard oxygen Gr2 base, Gr17 uses low oxygen Gr1 base for better ductility. Gr7 is reserved for strong reducing acid working conditions. Our Gr17 titanium wire is supplied to seawater and hydrometallurgy EPC projects in Egypt, Ecuador and Portugal.

Product Features

Our cold drawn Gr17 titanium wire is fully annealed and pickled to remove surface oxide. Every coil passes dimension inspection and chemical composition test to strictly control oxygen and palladium content. Gr17 titanium wire is commonly processed into fine filter mesh, soft hanging wire and precision anti-corrosion small parts for seawater and mild chloride reactors.

Industry Applications

• Seawater & hydrometallurgy: mild chloride filter mesh, soft hanging wire, precision anti-corrosion spare parts
• Brine and coastal circulating system requiring low metal contamination
• Desalination and mining equipment fabrication projects in Egypt, Ecuador and Portugal

Quality Assurance

Every batch undergoes strict inspection before shipment:

• Full dimension tolerance inspection
• Tensile & elongation mechanical property testing
• Chemical composition testing for oxygen and palladium content
• Material Test Certificate (MTC) supplied for traceability

Our Service Advantages

• ✅ Spot stock available for fast delivery
• ✅ Custom cutting service, cut‑to‑size according to customer drawings
• ✅ Professional drawing interpretation, support non‑standard dimension processing
• ✅ ISO9001 certified, MTC certificates provided for each shipment
• ✅ Meet ASTM, ASME and GB international standards
• ✅ Global export service, same‑day shipment for in‑stock goods

Packaging & Shipment

Anti-tangle spool packaging, protective film + foam + heavy-duty seaworthy plywood case. Small trial orders and bulk container shipments are both accepted. MTC and chemical composition test documents can be attached for client material audit and tender qualification.

FAQ

Q: What is Gr17 titanium wire used for?
A: Gr17 low oxygen low palladium titanium wire targets mild chloride crevice corrosion scenarios requiring high ductility and low contamination.

Q: What is the difference between Gr17 and Gr16 titanium wire?
A: Gr17 uses low-oxygen Gr1 base with superior ductility. Gr16 is Gr2 standard oxygen base. Both contain 0.04~0.08%Pd for chloride crevice corrosion.

Q: Does Gr17 wire comply with ASTM B863?
A: Yes. Our Gr17 titanium wire fully complies with ASTM B863 and meets international seawater and hydrometallurgy tender standards.

If you have technical specifications or project requirements, feel free to send us your inquiry for quotation.
