itanium Wire Cut to Coil Length from Stock \| ERTi-1/2/5 AWS A5.16, Level-Wound Coil, Custom Metres, MTC 3.1, Baoji

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Titanium Wire Cut to Coil Length from Stock | ERTi-1/2/5 AWS A5.16, Custom Metre Coil, MTC 3.1

Meta Description: Titanium wire cut to coil length from Baoji stock — ERTi-1/2/5 per AWS A5.16, continuous level-wound coil cut to your metre length, same heat/lot, bright-clean, vacuum-sealed, EN 10204 3.1 with measured interstitials. No full-drum forced buy; cut length tolerance stated before PO.

Overview — "Cut to Coil Length" Means Stock Coil, Your Metres

Not every job needs a full D200 spool or a 20kg drum. Some jobs need:

• Orbital weld on 6 metres of Gr2 pipe → 8m wire, not 5kg spool
• Bench fixture repeat run → 30m fixed feed, zero leftover scrap
• Automated carriage seam → continuous coil cut to exact traverse length + 10% trim
• Trial before drum buy → cut length from current qualified heat, same MTC

We cut from existing stock coil — not rewound scrap, not mixed heats. You get a continuous length off the same lot, cut clean, re-sealed, certed like the full spool.

What You Can Specify

Reference: ASTM B863 cut-straight length tolerance logic applies as a baseline; final figure quoted per Ø/length band — no "exact to the mm" claimed blindly on fine wire.

Why Cut From Stock Coil (Not "Buy Full Drum")

• No forced MOQ drum — pay for the length you weld
• Same heat as full spool — lot No. carries over, WPS correlation intact
• No re-melt, no mix — cut point is physical only; metallurgy unchanged
• Less scrap — orbital/automated runs get trim allowance, not 4kg leftover
• Fast — qualified heats cut/pack same working week after PO+lots confirm

Cut Quality Controls

• Clean shear / burr-minimised cut (no thermal burn at cut face)
• Ends capped or folded into coil core — no loose end scratch
• Roundness unchanged — cutting does not reshape diameter
• Cast/helix preserved for feeder use (if re-spooled, layer-wound to feeder type)
• Visual: no blue oxidation at cut, no lubricant, no steel-tool crossover
• Each cut coil tagged: AWS class + Ø + cut length + lot/heat + "CUT FROM STOCK COIL" mark

Diameter × Cut-Length Menu (Core Stock)

Sub-0.8mm or alloy ELI cut-coil → draw schedule quoted; not from "any random coil".

Traceability — Cut Length Still Gets Full Paper

• Same ingot→rod→coil lot No. as the parent spool
• EN 10204 3.1: measured O/H/N/C + tensile + diameter scan
• Cert line notes "cut length from heat ___", not a new heat
• 3.2 (SGS/BV/TÜV) PO-fronted, witnessed before cut
• ERTi (A5.16 filler) cert never merged with B863 base-wire line

Packaging for Cut Coil

• Vacuum foil + desiccant + aluminium barrier
• Option A: loose coil in sealed bag (tie-tag both ends)
• Option B: re-layer-wound on D100/D200 plastic spool (feeder-ready)
• Outer: plywood case / antistatic carton, "DRY / NO OIL / ARGON-CLEAN"
• Pre-ship photo: coil face / cut end / lot tag

When Cut-Coil Is the Right Call

• Orbital pipe welding with known seam length
• Fixture-fed automation (fixed stroke = fixed wire length)
• Sample before drum commitment
• Field repair with capped total metre budget
• Mixed-diameter kit: 1.2mm×20m + 1.6mm×15m in one crate

Enquiry Template (Copy-Paste)

AWS class: ERTi-1 / 2 / 5 ___
Diameter: ___ mm
Cut length: ___ m per coil (qty ___ coils)
Trim allowance: +5% / +10% / none ___
After-cut form: loose coil / re-spool D100-D200 / straight cut ___
Feeder type: push / pull / dual ___
Base metal + WPS: ___
Cert: 3.1 / 3.2 (TPI: ___)
Incoterm: EXW Baoji / FOB Shanghai / DAP ___
Destination: ___

FAQ — Titanium Wire Cut to Coil Length

Q1: Is cut coil from a different heat than the full spool?
A: No. Same parent stock coil, same lot/heat. Cert carries the heat No.; line reads "cut length from heat ___".

Q2: Length tolerance?
A: Quoted per Ø + length band before PO (ASTM B863 cut-length logic as baseline). We state the number in the quote — no "approximate" surprise at receipt.

Q3: Does cutting hurt cast/helix for MIG feed?
A: No. Diameter and cast are set in drawing+wind. If re-spooled, we layer-wind to your feeder type.

Q4: Minimum cut length?
A: 5m standard on core Ø; shorter considered for R&D with setup noted in quote.

Q5: Full MTC on a 10m cut?
A: Yes — 3.1 with measured interstitials. Cut length does not downgrade the cert.

Q6: Can I mix diameters in one crate?
A: Yes — each cut coil individually tagged, one cert pouch, one PL/CI.

Q7: Re-spool to D200 after cut?
A: Optional. Loose coil in vacuum bag is cheaper; D200 re-wind is feeder-ready.

Q8: Orbital weld use?
A: 0.8–1.6mm cut coil is standard for orbital. State pipe Ø + seam length → we calc trim.

Q9: Faster than full drum?
A: Usually yes on core heats — no drum fill, just cut+seal. Lot confirmed → same working-week pack.

Q10: Price basis?
A: Per-metre rate + cut/pack handling; small-batch tier stated upfront, no hidden surcharge after PO.

Request a Quote

Email: sales@[yourdomain].com

Send class + Ø + cut length + qty + feeder type. Reply in 24h: lot status, per-metre rate, cut tolerance, dispatch window.

About: Baoji Titanium Valley cut-coil line. Titanium wire cut to length from qualified stock coil — ERTi-1/2/5 per AWS A5.16, continuous length, same heat/lot, bright-clean, vacuum-sealed, EN 10204 3.1. No forced drum, no mixed heat, no cert downgrade for being short. Cut the length, keep the pedigree.
