High neck butt welding titanium flange

[ Material Performance ]
1. Mechanical property: titanium material is light and high-strength, the increased long neck can buffer the bending moment of the pipe, and it is resistant to vibration, cold and hot cycle fatigue, and it is not easy to deform and crack in long-term use;
2. Anti-corrosion performance: stable passive film is generated on the surface, long-term contact with seawater, salt mist, acid and alkali media will not produce pitting corrosion and stress corrosion;
3. Physical and chemical characteristics: non-magnetic, excellent low temperature toughness, high material purity, no heavy metal impurities are separated out when conveying medicine and high-purity fluid;
4. Application advantages: the butt welding structure has high connection strength, the weld joint is far away from the sealing area, and the sealing effect is durable and stable under high pressure.

[ Process structure ]

1. It is integrally forged and formed, and the flange plate and the high neck are seamless, without stratification, perforation and leakage hazards;
2. Extended tapered neck can effectively disperse the stress generated by thermal expansion and cold contraction of the pipe and reduce the risk of weld fatigue damage;
3. Precision standard welding groove, good fusion effect with titanium tube welding, and the corrosion resistance of weld joint is the same as that of base metal;
4. Vacuum annealing shall be carried out after forming to eliminate internal stress during processing. Each finished product shall be subject to flaw detection and hydraulic pressure maintaining test, with reliable sealing performance.

[ Application field ]

1. Chemical chlor-alkali industry: acid and alkali medium and high pressure transmission main pipes, supporting flange fittings for electrolytic equipment;
2. Sea water environmental protection industry: sea water desalination unit, ship cooling, power plant desulfurization high-pressure anti-corrosion pipeline;
3. Medical semiconductor industry: high-purity liquid medicine, special vacuum gas clean high pressure transmission pipeline;
4. Power new energy industry: nuclear power condenser, electrolyte circulation high-pressure pipeline;
5. Marine heavy industry: offshore platform, anti-corrosion high-pressure connection accessories of deep-sea test equipment.
